How to open the charging cover of the charging port cover actuator for electric cars

Electric vehicle batteries have a sealing cover. To open the sealing cover, you need to use scissors and a screwdriver. After the sealing cover is broken, the sealing cover cannot be resealed, and the battery cannot be used.

1. Insert scissors along the edge of the sealing cover. 2. Firmly pry the scissors upwards as shown in the picture. as the picture shows

3. After using scissors to pry the opening, use a screwdriver to continue to pry it bit by bit. As shown in Figure 4, the sealing cover has been pried off. as the picture shows

Electric vehicle battery maintenance:

1. Don't change the charger at will, and don't lift the speed limit of the controller. The chargers of different manufacturers generally have individual requirements. Don't change the charger at will when you are not sure.

2. There are instructions on how to protect the charger in the general instructions for protecting the charger.

3. To prevent long-term capacity discharge, do not run frequently after discharge. Charge when the battery is less than half charged.

4. For long-term use of the battery, it should be charged once a month.

5. When charging, it is strictly forbidden to cover the battery. It should be placed in a place with ventilation and heat dissipation.

6. When charging the battery, first insert the charger into the battery box, and then plug in the AC power supply.

Wiring method of electric actuator

This article introduces the wiring method of the electric actuator in detail; if you think the answer is helpful to you, please raise your hand and give a thumbs up to the VTON electric actuator!

Electric actuators are used to control valves with 0°～° rotation, such as butterfly valves, ball valves, dampers, flapper valves, plug valves, louver valves, etc., with // AC power as the driving power, with 4-current signal or 0-DC voltage The signal is a control signal, which can move the valve to the required position to realize its automatic control, and the maximum output torque is up to m.

However, the electric actuator is different from the manual valve. It involves parameter setting and debugging, as well as electrical wiring, which requires more professional personnel to complete it. Therefore, it is necessary to share the wiring method of the electric actuator of the VTON VTON electric actuator.

1. Electrical wiring

1. Electrical wiring

A wiring diagram is posted inside the actuator (inside the electrical compartment cover).

Wire according to the provided wiring diagram, such as power supply, control power supply, internal wiring and grounding, etc.

If necessary, connect an external power supply to the dryer to keep the inside of the actuator dry.

Make sure that the wiring of the terminals is secure.

Make sure that an external controller only acts on one electric actuator (do not act on 2 or more actuators at the same time).

After wiring, make sure that the inside of the actuator is clean and free of debris.

2. Check the direction of rotation

In the three-phase actuator, the rotation direction of the actuator should be checked before electric operation (the operator).

If the running direction is wrong, the limit switch will not work, resulting in jam damage or motor overheating.

Manually place the actuator in the 50% open (or closed) position, supply power to the actuator, and confirm the direction of rotation.

If the open signal is given and the actuator rotates in the open direction, the direction is correct. However, if the direction is reversed, the wiring needs to be changed, and any 2 of the 3 power cables are interchanged.

Check the direction of rotation again and confirm.
